CHIEF OXCM1U - Page 5

Installation Instructions OXCM1U
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
#2
5/32” (included)
1/2”
9/16”
3/8"
C (4)
E (4)
[Interface Bracket Hardware Kit]
A (4)
B (4)
D (4)
F (4)
G (4)
X (2)
M6x25mm
M8x20mm
M8x30mm
M6x16mm
.750x.323x.250
.750x.344x.500
Z (16)
1/4-20 x 5/8"
Y (4)
5/16 x 5/8"
5/16"
P (1)
5/16-18 x 2"
L (2)
[Interface bracket]
K (1)
[Center wind shield]
W (4)
3/8"
N (1)
J (2)
[Side wind shield]
1/4-20 x 2"
Q (1)
1/4-20
1/4-20 x 1 1/4"
BB (4)
5/16-18
CC (8)
5/16"
DD (16)
1/4"
H (2)
[Mount assembly]
R (1)
5/16-18
S (2)
5/16"
T (2)
1/4"
EE (1)
5/32"
U (2)
3/8-16 x 4"
V (2)
3/8-16
M (1)
#10-24 x 1/2"
FF (1)
[X-large adapter]
GG (2)
[Side cover]
JJ (1)
[X-large rail]
HH (4)
[Wind shield connector]
[Interface Lockout Bag] - (2) - (qty. per bag)
[Box-column Hardware Kit] - (2) - (qty. per bag)
AA (4)
1/4 x 3/4"
