Installation Instructions TIL1X2PT / TIL1X3PT / TIL1X4PT / TILVABPT
22
DIMENSIONS...cont’d
TiLED 3X3 CONFIGURATION
DIMENSIONS: INCHES
[MILLIMETERS]
