CHIEF RMT2 - RMT2 Dimensions; RLT2 Dimensions

Installation Instructions RMT2/RLT2/RXT2
3
DIMENSIONS-RMT2
DIMENSIONS-RLT2
16.50
15.75
MAX
19.94
7.87
TOP MOUNTING
HOLE TO CENTERLINE
NOTCH ON WALL PLATE
7.00
WALL
OPENING
2.50
CENTERLINE
TO BOTTOM OF
WALL PLATE
OPENING
22.00
.34
1.00
8.38
11.00
16.00
5.19
11.49
1.96
- TILTS BACK 5.4°
-CABLE ACCESS
WHEN KICKSTAND
IS ACTIVATED
12°
MAX TILT
16.50
15.75
MAX
28.69
7.87
TOP MOUNTING
HOLE TO CENTERLINE
NOTCH ON WALL PLATE
7.00
WALL
OPENING
30.75
.34
1.00
8.38
15.38
16.00
5.19
24.00
2.50
CENTERLINE
TO BOTTOM OF
WALL PLATE
OPENING
11.49
1.96
- TILTS BACK 5°
-CABLE ACCESS
WHEN KICKSTAND
12°
