CHIEF RMT2 - Tools Required for Installation; Parts List and Hardware

RMT2/RLT2/RXT2 Installation Instructions
6
TOOLS REQUIRED FOR INSTALLATION
PARTS
7/32" (5.5mm) #2 1/2" (12.7mm)
5/16" (7.9mm)
GC(6)
M4 x 25mm
GG(6)
M5 x25mm
GK(6)
M6 x 35mm
GN(6)
M8 x 40mm
1/2"(12.7mm)
A(1)
[wall plate]
B(1)
[left upright]
GA(8)
M4 x 16mm
GB(6)
M4 x 20mm
GD(6)
M4 x 35mm
GE(6)
M5 x16mm
GF(6)
M5 x20mm
GI(6)
M6 x16mm
GJ(6)
M6 x 25mm
GL(6)
M8 x 20mm
GM(6)
M8 x 30mm
GO(6)
M8 x 50mm
GP(8)
1/4"(6.4mm)
GQ(8)
GS(8)
[universal washer]
D(4 or 6)
5/16 x 2 1/2"
E(4 or 6)
5/16"
F(4 or 6)
[concrete anchor]
C(1)
[right upright]
For below kit, quantities
are 4 for RMT2 and RLT2,
6 for RXT2.
(RXT2 shown)
GH(6)
M5 x 35mm
G(1)
Hardware Bag
