CCH01726 3
STEP 6 - DIAGRAM 6: ATTACH DROPSIDE & CASTERS
After completing the assembly process you are advised to read and be aware of all Warnings, Cautions, Cleaning, Storage, Use and
Maintenance notices contained in this set of assembly directions and printed on the plastic pouch located on the underneath side of Crib
Spring
RR
RR
R. You will then place the complete set of assembly directions into the plastic pouch for future referral. We caution you not to
place excess hardware in the plastic pouch as it could present danger to a child if retrieved and it could possibly puncture crib mattress.
Check to be sure each screw and bolt is tightened securely, then check frequently to be sure all fastening devices remain tightened.
Place a purchased crib mattress on Crib Spring R and crib is ready for use.
Locate the two Crib Rods
KK
KK
K, Dropside Q, Washers X, Bumper SpringsG and
the two remaining Slotted/Phillips Machine Screws A. Insert a Crib RodK
downward through the holes in the following sequence:
1. 1.
1. 1.
1. The top rail of Dropside Q,
(with plastic teething rail), (Note: Gate Shoes
C
will be placed
to inside),
2.2.
2.2.
2. The L-Bracket on 4-Position Spring Hanger Bracket
SS
SS
S
,
3.3.
3.3.
3. A Bumper Spring
GG
GG
G,
4.4.
4.4.
4. (2) Washers X, 5. Bottom Rail of Dropside
Q.
6.6.
6.6.
6. A Bumper SpringG,
7.7.
7.7.
7. Hole in Angle BracketT. Place a Slotted/Phillips Machine Screw A into hole in top of Crib Rod
KK
KK
K and into receiving
bushing located in top corner post of Footboard O & Headboard
NN
NN
N. DO NOT USE A POWER SCREWDRIVER OF ANY TYPE TO TIGHTEN SCREW
AA
AA
A. Start Screw A (two or three turns) with your fingers into its threaded bushing to insure Screw A has a square fit. Once you are sure Screw
A fits squarely into its threaded bushing, tighten securely with a hand held (non-power driven) screwdriver. Attach remaining Crib Rod K to the
other end of Dropside Q
,
using the same procedure. Be sure Slotted/Phillips Machine Screw
AA
AA
A is tightened securely, check periodically and tighten
if needed.
Tip: To help Crib Rods
KK
KK
K
function more quietly we suggest you rub the crib rod with waxed paper or paraffin. You may want to repeat
this procedure periodically.
Locate the (4) CastersH, insert each into a lower corner post of Headboard
NN
NN
N & Footboard
OO
OO
O.
(Caster design may
vary according to your particular model.)
Note:
If crib is placed on exceptionally thick carpet, take care when crib is rolled as Casters
HH
HH
H
could catch on thick carpet pile and possibly cause breakage or damage to lower corner posts of crib.
ΦΦ
ΦΦ
Φ TO LOWER DROPSIDE:
Lift the Dropside slightly, push the foot latch toward the inside of
crib which will release the dropside to the lowest or “DOWN” position.
ΦΦ
ΦΦ
Φ TO RAISE
DROPSIDE: Lift up on the Dropside, rail will then lock into the “UP” position.
E
N
P
I
O
A
Q
K
S
G
D
H
B
T
A
E
B
S
R
K
H
Top rail
Bottom rail
Tab
Tab
Foot Latch on J
Plastic Pouch
G
X
Hook end
down
CRIB SPRING
RR
RR
R:
Be sure the smooth side of wire is placed
up as illustrated. Also,style of Crib Spring
RR
RR
R may differ with your model of crib.
Proper Spring G and
Washer X placement.
G
X
G
K
Q
O
S
See mattress size requirements
on page 4 under CAUTION.
To Next Page
