Page #8 background imageLoading...
Page #8 background image
DTSU666 series and DSSU666 series
three phase electronic energy meter
ZTY0.464.1448
User manual
Page 7, Total 21
added voltage for voltage circuit shall be 115% of the referenced voltage.
Shortest testing time
Δt
For instrument of class 0.5S and class1
6
max
600 10
Δt [ mi n]
n
k m U I
For instrument of class 2
6
max
480 10
Δt [ mi n]
n
k m U I
From the formula, k represents meter constant (imp/kWh), m represents measuring components,
Un represents referenced voltage (V) and Imax represents the maximized current (A).
3.4.Electrical parameters
Table 7 Electrical parameters
Specified operating voltage range
0.9Un1.1Un
Extended operating voltage range
0.8Un1.15Un
Ultimate operating voltage range
0 Un1.15Un
Power consumption of the voltage
circuit
≤1.5W and 6VA
Power consumption of the current
circuit
I
b
10A
≤0.2VA
I
b
≥10A
≤0.4VA
Data save time after power off
≥10 years
4.Key components adoption
Table 8 Key components adoption
Model
DTSU666
Metering chip
HT7036
Crystal
oscillator
5.5296MHz32.768kHz
Printed PCB
ZTY8.067.2267ZTY8.067.2837ZTY8.067.2288
Power
transformer
EE19-0.9mH-B
Current
HLX1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the CHINT DTSU666 Series and is the answer not in the manual?

CHINT DTSU666 Series Specifications

General IconGeneral
TypeThree-phase electronic energy meter
Rated Current5A
Starting Current0.004Ib
Frequency50/60Hz
DisplayLCD
MountingDIN rail
Operating Temperature-25°C to +55°C
Storage Temperature-40°C to +70°C
Protection LevelIP51
Rated Voltage3x230/400V
CommunicationRS485
Weight0.5 kg
StandardsIEC 62052-11
Accuracy Class0.5S
Humidity<95% non-condensing
