CHINT NVF5-2.2/TS4-B Quick Start-Up Wizard

F0.01
Command
Source
○
0：Integral Keypad
1：Digital Terminal
2：Communication
3：Remote Panel
0
F0.02
Main
Frequency
Reference
○
0：Digital Given
1：AI1
2：AI2
3：Reserve
4：High Speed Pulse HDI Reference
5：Preset Speed Reference
6：Simple PLC Reference
7：Close Loop PID Reference
8：Reserve
9：Potentiometer Reference
0
F0.05
Digital Given
○
F0.09-Min. Frequency～F0.08-Max. Frequency
5.00Hz
F0.14
Accelerate
Time 1
○
（0.0～6500.0）s
Depend on
Series
F0.15
Decelerate
Time 1
○
（0.0～6500.0）s
Depend on
Series
F0.20
Parameter
Factory Default
◎
0：No Effect
1：Fault Log Clear
2： Set to Factory Default （ Except Motor NP
Parameters and Parameter F7.11）
3：Reset Custom Parameter Group to Factory
Default （ Except Motor NP Parameters and
Parameter F7.11）
4：All Parameter Reset to Factory Default
5：Back Up Parameters
6：Using Back Up Parameters
7：Saving Back Up Parameters
Note ： Only when you are using backup
parameters,backup parameter are able to be
saved.Otherwise when power off then re-power
the inverter,except the updated parameters other
parameters are always initial value.
0
F2.00
Motor Type
○
0：AC Induction Motor
1：Reserve
2：Reserve
F2.01
Motor NP
Power
◎
（0.1 ～ 1000.0） kW
Depend on
motor type
F2.02
Motor NP
Voltage
◎
0V ～ Inverter Rated Voltage
Depend on
motor type
F2.03
Motor NP
Current
◎
（0.1～1000.0）A
Depend on
motor type
F2.04
Motor NP
Frequency
◎
0.01Hz ~ F0.07
Depend on
motor type
F2.05
Motor Poles
◎
2 ～ 24
4
F2.06
Motor NP RPM
◎
（0～60000）rpm
1430rpm
F2.22
Motor Auto
Tuning
◎
0：No Operation
1：Static Tune
2：Rotate Tune
0
F7.11
Parameter
Menu Mode
◎
1：Simple Menu Mode
2：Custom Menu Mode
3：Engineering Menu Mode
1

CHINT NVF5-2.2/TS4-B Specifications

General

Brand	CHINT
Model	NVF5-2.2/TS4-B
Category	Inverter
Language	English
