Chipolino ELITE - Assembly and Functions; Assembly Steps; Stroller Operation

3
This stroller is supplied partially assembled. In order to complete the assembly, you do not need any
tools.
The assembly, disassembly and functions are numbered from 1 to 17. Use the operations descriptions
given in this manual and their matching picture.
CAUTION! Follow exactly the instructions given and check the pictures.
CAUTION! After each operation, make sure that you have followed the instructions correctly.
CAUTION!Makesurethexingisstable,ascheckifthepinsjumpoutoftheopenings.
CAUTION! In most cases after the completion of an operation you will hear a clicking sound.
1 – UNFOLDING THE STROLLER
2 – ASSEMBLY AND REMOVAL OF THE FRONT WHEELS
To remove the wheel, press the button and pull the wheel out.
3 – ASSEMBLY AND REMOVAL OF THE REAR WHEELS
To remove the rear wheel, pull out the rear wheel button with one hand and remove the wheel from the
frame with other hand.
4 – ATTACHMENT AND REMOVAL OF FRONT BUMPER
Press the button and remove the bumper bar from the seat frame.
5 – SEAT ASSEMBLY
5-1 Seat can be installed in two directions – baby is facing the parent (face to face mode) or baby is
facing the motion.
5-2 and 5-3 Removal the seat
Press the buttons on both sides and remove the seat form the frame.
6 - ATTACHMENT AND REMOVAL OF CANOPY
CAUTION!Alwaysattachthecanopytothebackresttopreventthebabytofallandinjure!
To remove the canopy (6-2), pull both clips from the seat frame and pull the canopy from backrest.
7 –STORAGE BASKET ATTACHMENT
Press the removal buttons on both sides and remove the seat form the frame.
8 – FOLDING THE STROLLER
8-1 and 8-2 – Set the backrest in folding position.
8-3, 8-4, 8-5 and 8-6 – Apply the parking device and place your leg on rear axis. Press the folding button,
adjustthehandletoitslowestpositionandpushtheframeforwardsuntilitfolds.
9 – HEIGHT ADJUSTMENT OF HANDLE
Note: the lock of required position is always accompanied with click sound.
10 – BACKREST ADJUSTMENT
Pull the lever upwards and set the backrest in desired position.
Note: the lock of required position is always accompanied with click sound.
11 – CANOPY – OPEN AND FOLD
Push or pull with your hand to fold or open the canopy.
12 – LEG REST ADJUSTMENT
Press the buttons simultaneously at both sides to set the leg rest from high to lower position.
Pull with your hand the leg rest to set it from low to higher position.
13 – PARKING DEVICE
13 (1) – Block the rear wheels
13 (2) – Release the rear wheels’ motion.
ASSEMBLY INSTRUCTIONS AND FUNCTIONS
FUNCTIONS
ASSEMBLY
