5
INSTALLATION IN THE VEHICLE ACCORDING TO CHILD’S WEIGHT.
ROUTING OF THE SEAT BELTS
fig. 4 fig. 5
fig. 6
According to child’s weight, install the car seat in rear facing (fig. 4) or forward facing (fig.5)
position.
ATTENTION! Do not place the child in a sleeping bag, blanket or quilt before putting him in
the car seat, because thus the shoulder belts will not snug well and will endanger child’s safety.
IMPORTANT! Always make sure that the 3-point safety belts are well fixed, they are not
twisted or pinched in vehicle’s door. After each recline adjustment, pull the straps well and fix
them with the red clip.
NOTE: Before placing a child in the child restraint system, the seat must be set in the
maximum recline position for rear facing use, or in the sitting position for forward facing use.
See following picture’s solid pattern and dash pattern – fig.6.
To achieve that, use the recline handle located in front of the child restraint between the
sitting part and the base to adjust to the desired position. Pull up the recline handle and hold it,
at the same time pull back or forward the sitting part of the child restraint, then release the
recline handle while the sitting part is in the desired position and push it until you hear a clear
audible click sound.
