Chroma 61501 - Page 67

Application
5-3
LIST mode example:
COUNT = 1 [ LIST ]
TRIG = AUTO
BASE = TIME
<SHIFT> <ENTER> to Execute T
SEQ = 0 DEGREE = 90.0
[ LIST ]
Vs = 20.0 Fs = 50.00 DCs = 0.0
Ve = 80.0 Fe = 50.00 DCe = 0.0 S
WAVE = A TIME = 75.0 ms T
SEQ = 1 DEGREE = 0.0
[ LIST ]
Vs = 20.0 Fs = 50.00 DCs = 0.0
Ve = 20.0 Fe = 50.00 DCe = 100.0 S
WAVE = A TIME = 80.0 ms
T
SEQ = 2 DEGREE = 0.0 [ LIST ]
Vs = 20.0 Fs = 50.00 DCs = 0.0
Ve = 100.0 Fe = 400.00 DCe = 0.0 S
WAVE = A TIME = 100.0 ms
T
