Programmable AC Source 61501/61502/61503/61504 User’s Manual
3-26
Press
ENTER to save the output settings to channel 5. The display will show saving status
for about 3 seconds. The display is shown as below.
Then output setting in MAIN PAGE show in channel 5. The display is shown as below.
Then, press
PAGE/EXIT to return to MAIN PAGE.
Recalling from memory channel to MAIN PAGE is shown the following: In MAIN PAGE, press
SHIFT then Õ / - to run the RECALL function. The display is shown as below:
The cursor stays in channel 1. The user can press
1 - 9 to select channel or use
, , or press SHIFT then to change page to the destination. The cursor stays in
channel 2 after pressing 2 . The display is shown as below.
Press
ENTER, the display returns to MAIN PAGE automatically. And the output settings are
Vac = 120, F = 60, Vdc = 0, just as the settings saved in memory channel 2.
CHOICE 1 - 9, PRESS (ENTER) TO SAVE
4. Vac = 0.0 F = 60.00 Vdc = 0.0
5
. Vac = 230.0 F = 50.00 Vdc = 10.0 S
6. Vac = 0.0 F = 60.00 Vdc = 0.0 T
CHOICE 1 - 9 , PRESS (ENTER) TO RECALL
1
. Vac = 0.0 F = 60.00 Vdc = 0.0
2. Vac = 120.0 F = 60.00 Vdc = 0.0
3. Vac = 0.0 F = 60.00 Vdc = 0.0 T
CHOICE 1 - 9 , PRESS (ENTER) TO RECALL
1. Vac = 0.0 F = 60.00 Vdc = 0.0
2
. Vac = 120.0 F = 60.00 Vdc = 0.0
3. Vac = 0.0 F = 60.00 Vdc = 0.0 T
CHOICE 1 - 9, PRESS (ENTER) TO SAVE
4. Vac = 0.0 F = 60.00 Vdc = 0.0
5
. Vac = 0.0 F = 60.00 Vdc = 0.0 S
Saving now, do not shut down …
