What to do if Chroma 62050H-600S Power Supply shows Over Temperature Protection (OTP)?
If the Chroma Power Supply displays an Over Temperature Protection (OTP) error, it could be due to two reasons. First, the ambient temperature might be too high. Ensure the instrument is operated within a temperature range of 0 to 40°C. Second, the vent could be blocked. Make sure to clear the vent to allow for proper ventilation.
What to do if Chroma 62050H-600S Power Supply shows Over Current Protection (OCP)?
If the Chroma Power Supply shows an Over Current Protection (OCP) fault, it means the output current exceeds the specified limits or the OCP settings. To resolve this, remove the overload connected to the power supply or increase the OCP settings.
What to do if Chroma Power Supply shows Over Power Protection (OPP)?
If the Chroma Power Supply displays an Over Power Protection (OPP) error, it indicates that the output power is exceeding the specified limits or the OPP settings. To fix this, remove the overload or increase the OPP settings.
What does Input Error Protection 1 AC FAULT mean for Chroma 62050H-600S Power Supply?
If you encounter an Input Error Protection 1 AC FAULT on your Chroma Power Supply, it means that the voltage of the AC input line is either too low or too high. To solve this, measure the input voltage and adjust it if it exceeds the specified limits.
What to do if Chroma Power Supply shows Over Voltage Protection (OVP)?
If the Chroma Power Supply shows an Over Voltage Protection (OVP) fault, it means the output voltage exceeds the specified limits or the OVP settings. Check the OVP settings. If the protection state cannot be reset, contact your local sales agent for further assistance.
What does D/D FAULT mean on Chroma Power Supply?
If the Chroma Power Supply displays a D/D FAULT error, it could be due to a large transient current or damage to the D/D power stage. If a D/D FAULT protection occurs, first turn off the power supply and remove the load. Ensure that the cables are connected correctly, and then power it on again. If the issue persists, contact your local sales agent for further assistance.
Why does my Chroma 62050H-600S Power Supply show 'ERROR!!! MASTER OR SLAVE NO MATCH'?
If your Chroma Power Supply shows 'MATCH warning that the models are incompatible when connected in series or parallel (ERROR!!! MASTER OR SLAVE NO MATCH)', this means the model numbers do not match. Different model power supplies cannot be connected in series or parallel mode. If you need further assistance, contact your local sales agent.
Why does my Chroma 62050H-600S have no output voltage?
If the Chroma Power Supply is not providing any output voltage, it could be due to abnormal output voltage feedback or damage to the D/D power stage. If the protection state cannot be reset, contact your local sales agent.
How to fix Chroma DC Power Supply control issues via GPIB?
If you are unable to control the Chroma DC Power Supply via GPIB, it could be due to an incorrect address or a loose/disconnected GPIB cable. Update the address and check the cable connection, securing it with screws.
What does 'Current sharing cable connection error (C/S CABLE ERR.)' mean on Chroma 62050H-600S Power Supply?
If the Chroma Power Supply displays 'Current sharing cable connection error (C/S CABLE ERR.)', it means the current sharing cable is connected when used in series mode. Check if the cables are connected correctly. Contact your local sales agent for further assistance.
General| Model | 62050H-600S |
|---|---|
| Category | Power Supply |
| Manufacturer | Chroma |
| Output Voltage | 0-600 V |
| Output Type | DC |
| Display | LCD |
| Weight | 30 kg |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 70°C |
| Output Current | 0-8.5 A |
| Programming Interface | GPIB, USB, Ethernet |
| Dimensions | 426 x 132 x 500 mm |
Verify power is set to match the rated input of this power supply.
Connect the protective grounding cables to a good earth ground.
To avoid injury, death, or damage, refer to the explanation in the instruction manual.
Highlights essential operating/maintenance procedures with potential injury/death risk.
Lists the technical operating specifications for the 62000H Series models, including detailed tables.
Instructions for verifying contents and handling damage after unpacking.
Steps required before operating the power supply for the first time.
Details the power input ratings and connections for the instrument.
Details the power input ratings for different models and configurations.
Provides instructions for connecting the power supply's input power cable.
Explains how to correctly connect the remote sensing wires for accurate voltage.
Instructions for connecting output cables to the rear panel terminals.
Instructions for connecting output cables to the rear panel terminals.
Steps to power on the DC Power Supply and initiate self-tests.
Step-by-step guide to setting output voltage and current using front panel controls.
Explains how to configure system functions like setup, protection, and remote settings.
Configures system parameters including APG, buzzer, and power-on status.
Configures output parameters like voltage/current limits and slew rates.
Sets the minimum and maximum allowable output voltage.
Sets the minimum and maximum allowable output current.
Sets parameters for IV Curve generation, including mode, filter, and speed.
Selects control mode (CC or CV) for IV Curve measurement and drawing.
Details how to connect and configure multiple units in series or parallel.
Provides diagrams for connecting output cables for series and parallel configurations.
Instructions for connecting communication cables for series and parallel operation.
Configures the instrument to operate as a Master or Slave unit.
Steps to configure a unit as a Slave in series or parallel operation.
Steps to configure a unit as a Master in series or parallel operation.
Selects the operation mode as either Parallel or Series.
Sets the total number of Slave units connected in parallel or series.
Enables the Master/Slave control for coordinated operation of multiple units.
Details the instrument's protection functions, categorized into two classes.
Details the procedures for calibrating various output and measurement functions.
Configures communication parameters for remote control.
Selects the operating mode: CV/CC, TABLE, SAS, EN50530, or SANDIA.
Uses standard Constant Voltage/Constant Current modes for general DC power supply use.
Imports IV Curve data from Excel for solar cell simulation.
Uses a built-in model for solar cell curve simulation.
Utilizes the built-in EN50530 formula for solar cell IV curve generation.
Uses the built-in SANDIA formula for solar cell curve simulation.
Allows programming output sequences with voltage, current, and timing settings.
Details how to add and configure sequences within a program.
Initiates or aborts the execution of programmed sequences in LIST MODE.
Steps to run a LIST MODE program and confirm execution.
Allows setting a run time voltage program with start, end, and duration.
Initiates or stops the execution of a V_STEP programmed sequence.
Steps to run a V_STEP program and confirm execution.
Allows editing IV Curves and creating IV-Sequences for solar simulation.
Details how to add and configure sequences for IV Programs.
Initiates or aborts the execution of an IV PROGRAM.
Steps to run an IV PROGRAM and confirm execution.
Guides on configuring parameters for GPIB, Ethernet, RS-232C, and RS-485.
Procedure for setting up Ethernet interface for remote control.
Details how to set IP, Subnet Mask, and Gateway for Ethernet connection.
Details the syntax and parameters of all DC Power Supply commands.
Explains the syntax for common commands and queries defined by IEEE488.2.
Details SCPI commands specific to the 62000H Series power supply.
Sets various instrument configurations like beeper, remote, output, foldback, APG, and brightness.
Commands for controlling source parameters like voltage, current, and slew rate.
Commands to fetch real-time measurements of voltage, current, power, and status.
Commands for managing program execution, linking, and counting.
Commands for querying IV Curve parameters like VOC, ISC, VMPp, IMPp.
Commands for setting SAS Mode parameters like VOC, ISC, VMPp, IMPp.
Commands for controlling the output state and mode.
Guides on basic Ethernet setup and operation for the 62020H-150S model.
Provides a table of common problems, their causes, and suggested resolutions.
