Chrontel CH7511B - Reference Board Bill of Materials (BOM)

CHRONTEL AN-B014
14 206-1000-014 Rev. 1.7 2020-07-14
3.2 Reference Board Preliminary BOM
Table 2: CH7511B/7512B Reference Design BOM List
Item
Quantity
Reference
Part
1
23
C1, C2, C3, C4, C5, C8, C9, C10, C11, C12, C13, C14,
C15, C16, C17, C18, C19, C20, C21, C22,
C23, C25, C27
0.1uF
2
2
C6, C7
10uF
3
2
C24, C26
22pF
4
2
D1, D2
P504CT-ND
5
2
JP1, JP2
HEADER 3
6
3
JP10, JP11, JP12
HEADER 2
7
2
L1, L2
Bead
8
2
Q1, Q2
PMBS3904
9
2
Q3, Q4
BSS138CT-ND
10
2
Q5, Q7
H2N7002
11
2
Q6, Q8
MMBT3904
12
17
R1, R2, R3, R4, R5, R6, R7, R11, R12, R18,
R19, R20, R21, R22, R23, R50, R58
10K
13
1
R8
50
14
7
R9, R10, R32, R33, R34, R36, R38
6.8k
15
1
R13
10K(1%)
16
1
R14
100K
17
1
R15
1K
18
16
R16, R17, R24, R25, R26, R27, R40, R41, R42,
R43, R48, R49, R51, R52, R53, R54,
100
19
1
R35
1.8k
20
2
R37, R56
470
21
2
R39, R57
50k
22
2
R28, R29
0
23
3
SW1, SW2, SW3
P8058SS-ND
24
1
U1
IRU1206-18
25
1
U2
DP_Sink
26
1
U3
CH7511B/7512B
27
1
U4
CH9904 (SOIC-8)
28
2
U5, U7
SI4953
29
1
Y1
27MHz
