4WD
Normal Four-Wheel-Drive High Range - Employs inter-
axle differential. Allows front and rear wheels to rotate at
different speeds. All road surfaces.
4WD LOCK
Four-Wheel-Drive Lock (4WD LOCK)- Locks the transfer
case inter-axle differential. Forces front and rear wheels
to rotate at the same speed. Additional traction for loose,
slippery road surfaces only.
4WD LOW
Four-Wheel-Drive Low Range (4WD LOW)- Low speed 4
wheel drive. Locks the transfer case inter-axle differen-
tial. Forces the front and rear wheels to rotate at the same
speed. Additional traction and maximum pulling power
for loose, slippery road surfaces only. Do not exceed 25
mph (40 km/h).
N
Neutral - Disengages both the front and rear driveshafts
from the powertrain. To be used for flat towing behind
another vehicle. See Recreational Towing for more infor-
mation.
270 STARTING AND OPERATING
