F8 10 Amp Red
Ignition Run/Start for
Cluster/Transfer
Case/Seat Sw. Back
lighting
F9 10 Amp Red
Satellite Digital Audio
Receiver (SDAR)/
Digital Video Disc
(DVD) Battery Feed
F10 10 Amp Red Spare
F11 10 Amp Red Heated Mirrors
F12 20 Amp Yellow Cluster Battery Feed
F13 10 Amp Red
Ignition Run HVAC
Module/Heated Rear
Glass (EBL) Relay
F14 10 Amp Red
ABS Module Ignition
Run
F15 15 Amp Blue
Battery Feed Blue
Tooth, Compass/Trip
Computer (CMTC),
Sentry Key Diagnos-
tics
F16 20 Amp Yellow
Reconfigurable Power
Outlets
F17 20 Amp Yellow
Ignition Run / Rear
Park Assist / Second
Row Heated Seats
F18 20 Amp Yellow Cigar Lighter Ignition
F19 10 Amp Red Spare Fuse
F20 15 Amp Blue
Heating & Air Condi-
tioning w/ATC Only
Battery Feed
F21 25 Amp Natural Amplifier Battery Feed
400 MAINTAINING YOUR VEHICLE
