Page #403 background imageLoading...
Page #403 background image
Cavity
Cartridge
Fuse /
Relay
Mini Fuse Description
23 20 Amp
Yellow
Trailer Tow
24 15 Amp
Blue
A/C Clutch
25 15 Amp
Blue
Stop Lamp Switch
26 Spare
27 20 Amp
Yellow
Run/Start Relay Feed
28 Spare
29 Relay Run Start
30 Relay Run Remote
31 Spare
32 Relay Starter
Cavity
Cartridge
Fuse /
Relay
Mini Fuse Description
33 Relay Electronic Automatic
Transaxle (EATX)
34 Relay AC Clutch
35 Relay Fuel Pump Rly
36 Spare
37 Relay Stop Lamp Switch
38 Spare
39 Relay Blower Motor
40 Relay Auto Shut Down
(ASD) Rly
MAINTAINING YOUR VEHICLE 403
7
