Cavity Cartridge Fuse Mini-Fuse Description
1 – – Fuse – Spare
2 40 Amp Green – Radiator Fan #1 – If Equipped
3 50 Amp Red – Power Steering #1 / Radiator Fan (6.2L Super-
charged) – If Equipped
4 30 Amp Pink – Starter
5 40 Amp Green – Electronic Stability Control
6 30 Amp Pink – Electronic Stability Control
7 – – Fuse – Spare
8 20 Amp Blue – Police Ignition Run / ACC # 2
9 – 20 Amp Yellow All-Wheel Drive Module – If Equipped
10 – 10 Amp Red Security – If Equipped / Under hood Lamp –
Police
11 – 20 Amp Yellow Horns
12 – 10 Amp Red Air Conditioning Clutch
13 – – Fuse – Spare
510 MAINTAINING YOUR VEHICLE
