Cavity Fuse Circuits

23 15 Amp

Blue

Sound Booster (Amplifier)

24 30 Amp

Green

Seat Heater

25 20 Amp

Yellow

Pneumatic Control Unit, Rear

Window Defroster

26 20 Amp

Yellow

Central Locking

30 Spare (Coupe)

30 15 Amp

Blue

Radio (Roadster)

31 15 Amp

Blue

Cigar Lighter, Glove Compart-

ment Light

32 15 Amp

Blue

Wiper, Washer Pump, Headlight

Flasher

33 5 Amp

Beige

Control Unit

Cavity Fuse Circuits

34 Spare (Coupe)

34 30 Amp

Green

Climate Control (Roadster)

35 15 Amp

Blue

Radio Frequency Remote Control,

Hazard Warning Flasher, Instru-

ment Cluster, Climate Control

36 30 Amp

Green

Climate Control (Coupe)

36 5 Amp

Beige

Exterior Mirror Adjustment

(Roadster)

37 7.5 Amp

Brown

Circulating Air, Instrument Clus-

ter, Radio Frequency Remote

Control, Climate Control, Central

Control Unit

MAINTAINING YOUR VEHICLE 301
