Cavity Mini Fuse Description
29 20 Amp Yel-
low
Cluster, CHMSL, Stop
Lights, Anti-Lock Brake
System (ABS)
30 10 Amp Red Ignition Switch
31 20 Amp Yel-
low
Hazard
34 Spare
35 Spare
36 20 Amp Yel-
low
Electronic Automatic
Transaxle (EATX) Solenoid
37 25 Amp
Natural
ASD
38 20 Amp Yel-
low
Fuel Pump
39 20 Amp Yel-
low
A/C Clutch, MTV
Cavity Mini Fuse Description
44 25 Amp
Natural
Rear Heated Seats
45 10 Amp Red Anti-Lock Brake System
(ABS) Ignition Run
46 20 Amp Yel-
low
Passenger Door
47 20 Amp Yel-
low
Driver Door
48 15 Amp Blue PLG, OHC, Body Control
Module (BCM), Naviga-
tion, Hands-Free Phone
(HFM)
49 25 Amp
Natural
Amplifier
50 15 Amp Blue HVAC, DVD, RAD, CLK,
SKREEM
MAINTAINING YOUR VEHICLE 409
