Chrysler Sebring - Page 408

Cavity
Cartridge
Fuse
Mini Fuse Description
10 —
20 Amp
Yellow
Battery Feed —
Cabin Compart-
ment Node
(CCN)
11 —
15 Amp Lt
Blue
Selectable Power
Outlet
12 —
20 Amp
Yellow
—
13 —
20 Amp
Yellow
—
14 —
10 Amp
Red
Ignition Off
Draw (IOD) —
Cabin Compart-
ment Node
(CCN)/ Interior
Lighting
Cavity
Cartridge
Fuse
Mini Fuse Description
15
40 Amp
Green
—
Battery Feed —
Radiator Fan Re-
lay
16 —
15 Amp Lt.
Blue
IGN Run/ACC
— Cigar Lighter/
PWR Sunroof
Mod
17 —
10 Amp
Red
Ignition Off
Draw (IOD) —
Wireless Control
Module (WCM)/
Clock/Steering
Control Module
(SCM)
18
40 Amp
Green
—
Battery Feed —
Auto Shutdown
(ASD) Relay
406 MAINTAINING YOUR VEHICLE
