Cavity
Cartridge
Fuse
Mini Fuse Description
19 —
20 Amp
Yellow
Ignition Off
Draw (IOD) —
Power Amp Feed
2 - if equipped
20 —
15 Amp Lt.
Blue
Ignition Off
Draw (IOD) —
Radio
21 —
10 Amp
Red
—
22 —
10 Amp
Red
Ignition Run —
Climate
Controls/Hot
Cupholder - if
equipped
23 —
15 Amp Lt.
Blue
Auto Shutdown
(ASD) Relay Feed
3
Cavity
Cartridge
Fuse
Mini Fuse Description
24 —
25 Amp
Clear
Battery Feed —
PWR Sunroof
Feed
25 —
10 Amp
Red
Ignition Run —
Heated Mirrors -
If Equipped
26 —
15 Amp Lt.
Blue
Auto Shutdown
(ASD) Relay Feed
2
27 —
10 Amp
Red
Ignition Run —
Occupant Classi-
fication Module
(OCM)/Occupant
Restraint Control-
ler (ORC)
