Chrysler SRT8 2012 - Page 494

Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
2 60 Amp
Yellow
— Front PDC Feed #1
3 — — Fuse – Spare
4 60 Amp
Yellow
— Front PDC Feed #2
5 30 Amp
Pink
— Sunroof
6 40 Amp
Green
— Exterior Lighting #1
7 40 Amp
Green
— Exterior Lighting #2
8 30 Amp
Pink
— Interior Lighting/
Washer Pump
9 30 Amp
Pink
— Power Locks
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
10 30 Amp
Pink
— Driver Door
11 30 Amp
Pink
— Passenger Door
12 — 20 Amp
Yellow
Cigar Lighters, Instru-
ment Panel & Power
Outlet Console Rear
15 40 Amp
Green
— HVAC Blower
16 — — Fuse — Spare
17 — — Fuse — Spare
18 — 20 Amp
Yellow
Active Dampening
Module
19 — — Fuse — Spare
20 — — Fuse — Spare
492 MAINTAINING YOUR VEHICLE
