Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
43 — 25 Amp
Natural
Rear Heated Seats/
Steering Wheel
44 — 10 Amp
Red
Park Assist/Blind
Spot/Camera
45 — 15 Amp
Blue
Cluster/Rearview
Mirror/Compass
46 — 10 Amp
Red
Adaptive Cruise Control
47 — 10 Amp
Red
Adaptive Front Lighting
48 — 20 Amp
Yellow
Active Suspension
49 — — Fuse — Spare
50 — — Fuse — Spare
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
51 — 20 Amp
Yellow
Front Heated Seats
52 — 10 Amp
Red
Heated Cupholders/
Rear Heated Seat
Switches
53 — 10 Amp
Red
HVAC Module/In Car
Temperature Sensor
54 — — Fuse — Spare
55 — — Fuse — Spare
56 — — Fuse — Spare
57 — — Fuse — Spare
58 — 10 Amp
Red
Airbag Module
59 — — Fuse — Spare
60 — — Fuse — Spare
494 MAINTAINING YOUR VEHICLE
