CIPU CSPPV711 - Pump Run Under Pre-programmed Conditions; Pump Run under MODE1;MODE2

9
NOTE: PRM for S2 and S4 or S1 and S3 are always the same.
The default for S1 and S3 is2400RPM, the adjustable range is 2400 to 2850RPM.
The default for S2 and S4 is 1500RPM.The adjustable range is 1000 to 2400PRM.
3.4 Pump Run Under Pre -programmed Conditions
Pump has three quick start button ECO/CLEAN/BOOST, as below figure. The default speed is
1500, 2400, 3250RPM respectively.
1) Be sure the pump is power on.
2) Press one of ECO/CLEAN/BOOST, the LED light on screen will be lit.
3) The screen will display STOP for 1 second, and run 2850PRM for 5 minutes. After 10
minutes, the pump will run on the select
ed speed.
4. Pump Run under MODE1/MODE2
4.1 MODE 1/MODE2 Introduction
MODE 1 MODE 2
16 hours running cycle 24 hours running cycle
Stage Start
Time
Running Hour Default
Speed
Quick
Start
Button
Stage Start
Time
Running
Hour
Default
Speed
Quick
Start
Button
S1 6:00AM 3
(adjustable)
2400RPM
(adjustable)
CLEAN S1 12:00
PM
6
(adjustable)
1500PM
(adjustable)
ECO
S2 9:00AM 5
(adjustable)
1500PM
(adjustable)
ECO S2 6:00
AM
3
(adjustable)
2400RPM
(adjustable)
CLEAN
S3 6:00PM 3
(adjustable)
2400RPM
(adjustable)
CLEAN S3 9:00
AM
9
(adjustable)
1500PM
(adjustable)
ECO
S4 9:00PM 5
(adjustable)
1500PM
(adjustable)
ECO S4 6:00
PM
6
(adjustable)
2400RPM
(adjustable)
CLEAN
1000-2400RPM
DEFAULT: 1500
CLEAN
2400-2850RPM
DEFAULT: 2400
2850-3450RPM
DEFAULT: 3250
ECO BOOST
Indicator Light
