17
ILLUSTRATED PARTS LIST
Ref.No. Part. No. Description QTY Remark
1 647253571 Cover 1
2 65431042080 O-Ring 1
3 647252704 Basket 1
4 647253501 Pump Housing 1
5 65431032080 O-Ring 1
6 65212025000 Screw ST4.2*38 2
7 647254703 Diffuser 1
8 647274871000 Impeller For CSPPV711 1
9 65431168080 O-Ring 1
10 65028014000 Seal Assembly 1
11 647254702 Pump Cover 1
12 65244015000 Gasket M10 10
13 65244032000 Spring Washer M10 6
14 65225003000 Screw 3/8-16*1 1/2 UNC 6
15 65023399000 Variable Speed 1.5HP Motor For CSPPV711 1
16 65221008000 Screw M10*25 4
17 65232001106 Nut 3/8-16 6
18 65432002080 Drain Plug Gasket 2
19 648860105 Drain Plug 2
20 65231002106 Nut M6 2
21 65244016000 Gasket M6 2
22 65224003000 Screw M6*20 2
23 647254704 Mounting Foot 1
24 647254705 Supporting Foot 1
25 647253572001 1.5''Adaptor Assembly 2
26 647253573000 Check Value 1
To Next Page
