7.Alert and Warnings
The pump displays all alerts and warnings on the control panel. When an alarm or warning
condition exists, the corresponding LEDs will be lit on the display. All control panel buttons are
disabled until the alarm or warning is acknowledged with the ENTER button. Disconnect power
to the pump and wait until the screen has all turned off.
POWER OUT FAILURE – Incoming supply voltage is less than 190 VAC.
PRIMING ERROR – If the pump is not defined as primed within the maximum priming time it
will stop and generate a priming alarm for 10 minutes, then attempt to prime again. If t
he pump
cannot prime within 5 attempts it will generate a permanent alarm and have to be manually
reset.
OVERHEAT ALERT – If the drive temperature gets over 103 Degrees Fahrenheit the
pump will slowly reduce speed until the drive temperature condition drops.
OVER CURRENT – Indicates that the drive is overloaded or the motor has an electrical
problem. If they do not clear after multiple restart attempts the drive should undergo a hard
power cycle. Disconnect main power by turning off the breaker long enough for the keypad
LEDs to turn off. After power is reconnected if this error con
tinues to reappear, the drive may
need service.
OVER VOLTAGE – Indicates excessive supply voltage or and external water source is
causing the pump and motor to rotate thereby generating excessive voltage in the drives
internal DC bus. If they do not clear after multiple restart attempts the drive should undergo a
hard power cycle. Disconnect main power by turning off the breaker long enough for the
keypad LEDs to turn off. After power is reconnected if this error continues to reappear, the
drive may need service.
1.Alert Code Details
Code Error Remarks
1 Get blocked or short circuit overheat
2 Voltage input exceeds limit
4 High input voltage
8 Low input voltage
16 Exceeds maximum speed
32 Speed is 0
64 Motor phase loss
128 Abnormal start-up
256 System configuration error
512 Stall at startup
1024 System operation error Contact the manufacturer
4096 Hardware test error Contact the manufacturer
8.Priming
The pump will prime and pre-prime providing the filter tank water and there is sufficient supply
from the suction point.
If you lose water from the filter tank it will be necessary to re-fill it before starting.
1. Remove the translucent lid and fill the filter tank with water.
