Cirrus SR22T Maintenance Manual

CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
24-30
Page 3
Serials w/o Perspective Avionics
EFFECTIVITY:
Figure 24-301
Electrical System Schematic - Serials w/o Perspective Avionics (Sheet 1 of 4)
ATT
GYRO
2A
2A
2A
25A
25A
STARTER
50A
50A
125A
EXTERNAL
POWER
A/C 1
CONDENSER
A/C 2
FAN
COMPR/CTRL
SR22_MM24_1426F
BAT 1
SWITCH
LANDING
LIGHT
LANDING LIGHT
SWITCH
15A
30A
ALT 2
SWITCH
BAT 2 SWITCH
AVIONICS
ESSENTIAL RELAY
AVIONICS
NON-ESSENTIAL
RELAY
AVIONICS
SWITCH
BAT 1
ALT 1
RELAY
FUEL OIL
ALT 1 ALT 2
PITOT
HEAT
ESSENTIAL
DIST
MAIN DIST
25A
25A
25A
25A
25A
VOLT REG
ALT 2
F
B
ALT 1
F
B
100A
40A
VOLT REG
GPS 2
ANN/ENG IND
MASTER CONTROL UNIT
CIRCUIT BREAKER PANEL
TRN CRD #1
AVIONICS
ESSENTIAL
BAT 2
ALT 1
SWITCH
LOW
VOLTS
ATTITUDE #1
PFD #1
STALL WARN
BATTERY 2
ALT 2
ESS POWER
ESSENTIAL
AUTOPILOT
AVIONICS
COM 1
GPS 1
FUEL PUMP
TRN CRD #2
MAIN BUS 2
ATTITUDE #2
PFD #2
CABIN LTS
ALT 1
START RELAY
NON-ESSENTIAL
AVIONICS NON-ESSENTIAL
MAIN BUS 1
PITOT/FAN
12V/ANR
STROBE LTS
NAV LTS
FLAPS
TRAFF/TAWS
COM 2
XPNDER
XM/WX
AUDIO PANEL
MFD
AVIONICS
FUEL QUANTITY
REC/INST LTS
PITCH TRIM
ROLL TRIM
ICE PROTECT
NOTE
Serials 22-0002 thru 22-1601, 22-1603 thru 22-1643 and 22-1645 thru 22-1662: 80A fuse.
Serials 22-0002 thru 22-1601, 22-1603 thru 22-1643 and 22-1645 thru 22-1662: 100A fuse.
Serials 22-1602, 22-1821, 22-1840, 22-1863 & subs.
15 Dec 2014

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
