Cirrus SR22T Airplane Maintenance Manual

22-11
Page 16
Serials 22-1602, 22-1840, 22-1863 & subs, 22T-0001 &
subs w/ A/C
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
15 Jun 2010
Figure 22-115
Pitch Servo Installation -
Serials 22-1602, 22-1840, 22-1863 & subs, 22T-0001 & subs w/ A/C (Sheet 3 of 3)
Serials 22-1602, 22-1840, 22-1863 & subs,
22T-0001 & subs w/ Air Conditioning.
13
9
4
23
22
21
4
24
6
4
6
0.01 inches
(0.25 mm)
maximun
2
SR22_MM22_2338
7
16
8
1
5
15
14
12
13
9
4
4
3
3
SPANNER
ADAPTER
ELEVATOR
CABLE (REF)
BRACKET
(REF)
BULKHEAD FS186
(REF)
LEGEND
1. Flapper
2. Plug
3. Screw
4. Washer
5. Capstan
6. Nut
7. Clamp
8. Bridle Cable
9. Bolt
10. Star Washer
11. Capstan Cover
12. Castellated Nut
13. Cotter Pin
14. Cable Guard
15. Tension Washer
16. Servo Motor Cover
17. Bridle Cable Stop-Ball
18. Bridle Cable End Fitting
19. Fairlead
20. Bracket
21. Pulley
22. Cable Keeper
23. Spacer
24. Servo Bracket Plate
Install outboard clamp assembly with bolt heads facing inboard and
inboard clamp assembly with bolt heads facing outboard. Align bolt
shafts approximately perpendicular to 0.0 buttock line.
NOTE
Before disassembly, mark location of bridle cable.
4
10
11
Ensure bridle cable does not rub on cable guards.
0.0 BUTTOCK LINE
(REF)
7
18
17
18.4 inches
(46.7 cm)
5.5 inches
(14.0 cm)
9
9
4
7
3
6
19
20
6
