CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
22-11
Page 9
Serials w/ Perspective Avionics
EFFECTIVITY:
Figure 22-112
System 55X Installation - Serials w/ Perspective Avionics (Sheet 2 of 2)
ALTITUDE
TRANSDUCER
(REF)
4
Serials w/ Perspective Avionics and System 55X.
LEGEND
4. Flight Guidance Program/Computer
SR22_MM22_3022A
15 Jun 2010
