Cirrus System 55X Autopilot - Page 6

22-11
Page 6
Serials w/ PFD and Avidyne Avionics
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
15 Jun 2010
Figure 22-111
System 55X Schematic - Serials w/ PFD and Avidyne Avionics (Sheet 2 of 3)
T
U
R
N
C
O
O
R
D
I
N
A
T
O
R
2
M
I
N
L
R
TURN COORDINATOR
SYSTEM 55X AUTOPILOT
ROLL TRIM CARTRIDGE
SR22_MM22_2145
PITCH TRIM CARTRIDGE
FLIGHT DIRECTOR
SWITCHES
PITCH TRIM SERVO
GNS 430 TRANSCEIVER #2
GNS 430 TRANSCEIVER #1
PFD FAIL
RELAY
ALTITUDE TRANSDUCER
PFD
