Cisco MERAKI MX65 - Back Panel Ports and Power; Side Panel Reset Button

Additional functions on the back panel are described below, from left to right.
WAN / Internet ports These two ports provide connectivity to the WAN.
LAN ports
These 8 ports provide connectivity to computers,
printers, access points, or Ethernet switches.
A steady green LED indicates bidirectional connectivity,
and flashing green indicates traffic.
PoE+ Ports
These 2 LAN ports provide connectivity to computers,
printers, access points, or Ethernet switches.
Each port outputs up to 30W of PoE power.
A steady green LED indicates bidirectional connectivity,
and flashing green indicates traffic.
Power input Designed for use only with the unit’s power supply.
The MX65 side panel
Additional functions on the back panel are described below, from left to right.
Reset button
Insert a paper clip if a reset is required.
• Press for 1 second to delete a downloaded
configuration and reboot.
