Figure 15: Wall mount using key-hole slots - C1101-4P
Key-hole slots
Key-hole slots-spacing: 3.024in (76.81mm)
1
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
28
Install and Connect the Router
Wall Mount Using Key-hole Slots
