Cisco 12000 Series Datasheet

All contents are Copyright © 1992–2006 Cisco Systems, Inc. All rights reserved. This document is Cisco Public Information. Page 3 of 9
Physical Chassis height
71.5 in. (181.6 cm)
72.5 in. (184.2 cm)1
Chassis width
17.25 in. (43.8 cm)
18.75 in. (47.6 cm)2
Chassis depth
22.0 in. (55.9 cm)
24.0 in. (61.0 cm)3
Weight
140 lb (64 kg)
4
390 lb (177 kg)
5
Chassis height
37.5 in. (95.25 cm)
Chassis width
19 in. (48.26 cm)
Chassis depth
22.0 in. (55.9 cm)
24.0 in. (61.0 cm)
weight
125 lb (57 kg)
275 lb (125 kg)
Chassis height
18.5 in. (47.0 cm)
Chassis width
17.3 in. (43.9 cm)
18.9 in. (48.0 cm)
Chassis depth
28.0 in. (71.1 cm)
Weight
140 lb (64 kg)
205 lb (94 kg)
Chassis height
8.75 in. (22.23 cm)
Chassis width
17.38 in. (44.15 cm)
18.9 in. (48.01 cm)
Chassis depth
27.5 in. (69.85 cm)
Weight
73 lb (33.18 kg)
103 lb (46.82 kg)
Chassis per rack One Two Four Eight
Electrical specifications for the AC input power
Total AC input power
1
4651 VA (max) per
chassis
2790 VA (max) per
chassis
Low Line 1708 VA
(max)
High Line 1950 VA
(max) per chassis
1341 VA (max) per
chassis
Rated input voltage
2
200–240 VAC nominal
(range: 180–264 VAC)
200–240 VAC nominal
(range: 180–264 VAC)
100–120 VAC (Low
Line) 200–240 VAC
(High Line) nominal
(range: 85–264 VAC)
100–120 VAC or 200–
240 VAC nominal
(range: 85–264 VAC)
Rated input line
frequency
50–60 Hz nominal
(range: 47–63 Hz)
50–60 Hz nominal
(range: 47–63 Hz)
50–60 Hz nominal
(range: 47–63 Hz)
50–60 Hz nominal
(range: 47–63 Hz)
Input current rating
(For any line cord)
10.3A maximum @
240 VAC
11.6A maximum @
240 VAC
17.2A (max) @ 100
VAC
10A (max) @ 200 VAC
6A maximum @ 240
VAC
Source AC service
requirement
20A North America;
16A international
20A North America;
16A international
20A North America;
16A international
20A North America;
16A international
Electrical specifications for DC input power
Total DC input power 4212 W (max) 2430 W (max) 1630 W (max) 1280 W (max)
-48 VDC nominal in
North America
-48 VDC nominal in
North America
-48 VDC nominal in
North America
-48 VDC nominal in
North America
Rated input voltage
-60 VDC nominal in
the European
community
(range: -40.5 to -75
VDC)
-60 VDC nominal in
the European
community
(range: -40.5 to -75
VDC
-60 VDC nominal in
the European
community
(range: -40.5 to -75
VDC
-60 VDC nominal in
the European
community
(range: -40.5 to -75
VDC
Input current rating
For any DC input pair
52A maximum @ 40.5
VDC
3
60A maximum @ 40.5
VDC
45A maximum @ 40.5
VDC
35A maximum @ 40.5
VDC
1
Maximum system power under worst case conditions (worst case input voltage, etc) and does not necessarily reflect what a customer will see under typical
conditions for his configuration
2
For each power supply module
3
In the full redundant power configuration, power entry modules A1 and B1 provide redundant power for system load zone 1 (upper blower module and
upper card cage). Modules A2 and B2 provide redundant power for system load zone 2 (switch fabric card cage, lower card cage, and lower blower
module).
