Cisco 12000 Series Datasheet

All contents are Copyright © 1992–2006 Cisco Systems, Inc. All rights reserved. This document is Cisco Public Information. Page 5 of 9
Hardware components
(per base system)
 4 DC power supplies,
or 3 AC supplies, or
4 AC power supplies
 1 performance router
processor
 16 line-card slots with
15 line cards and 1
route processor or 14
line cards and 2
route processors (1:1
redundant)
 3 switch fabric cards
(SFCs)
 2 clock scheduler
cards (CSCs)
 2 alarm cards
 Air filters
 2 blower assemblies
 2 cable-management
trays
 Country-specific
power cords
 2 DC power supplies
or 2 AC supplies
 1 performance router
processor
 10 line-card slots with
9 line cards and 1
route processor or 8
line cards and 2
route processors (1:1
redundant)
 5 SFCs
 2 CSCs
 1 alarm card
 Air filter
 1 blower assembly
 1 cable-management
tray
 Country-specific
power cords
 2 DC power supplies
or 2 AC supplies
 1 performance router
processor
 6 line-card slots with
5 line cards and 1
route processor or 4
line cards and 2
route processors (1:1
redundant)
 3 SFCs
 2 CSCs
 1 alarm card
 Air filter
 1 blower assembly
 1 cable-management
tray
 Country-specific
power cords
 2 DC power supplies
or 2 AC supplies
 1 performance router
processor
 4 line-card slots with
3 line cards and 1
route processor or 2
line cards and 2
route processors (1:1
redundant)
 1 consolidated switch
fabric, clock
scheduler, and alarm
card
 Air filter
 1 blower assembly
 1 cable-management
tray
 Country-specific
power cords
Software components
(per base system)
 Cisco IOS XR or
Cisco IOS Software
Operating System
 Cisco Express
Forwarding for
distributed packet
forwarding
 Cisco IOS XR or
Cisco IOS Software
Operating System
 Cisco Express
Forwarding for
distributed packet
forwarding
 Cisco IOS XR or
Cisco IOS Software
Operating System
 Cisco Express
Forwarding for
distributed packet
forwarding
 Cisco IOS XR or
Cisco IOS Software
Operating System
 Cisco Express
Forwarding for
distributed packet
forwarding
Compatibility Cisco 12800: Line cards that support 2.5-, 10-, or 20-Gbps capability
Cisco 12400: Line cards that support 2.5- or 10-Gbps capability
Cisco 12000: Line cards that support 2.5-Gbps capability
Protocols IPv4, MPLS, Border Gateway Protocol Version 4 (BGPv4), Intermediate System-to-Intermediate
System (IS-IS), Open Shortest Path First Version 2.0 (OSPFv2.0), Routing Information Protocol
Version 2 (RIPv2), Internet Group Management Protocol (IGMP), Distance Vector Multicast Routing
Protocol (DVMRP), and Protocol Independent Multicast dense mode/sparse mode (PIM DX/SX)
Connectivity Packet over SONET/SDH (POS), Ethernet, ATM, copper (DS-3/E3), Channelized (CT3, ChOC-
3/CHSTM1, ChOC-12/CHSTM4, ChOC-48/CHSTM16); see Cisco IOS XR Software release notes for
specific connectivity support on the Cisco XR 12000 Series
Reliability System redundancy:
 Fabric card redundancy 4:1
 CSC redundancy 1:1
 Power supply redundancy (1:1 for DC; AC is load balancing)
 Blower redundancy 1:1
 Route processor redundancy 1:1
 Alarm card redundancy 1:1
 Dual homing through line cards
 Supports automatic protection switching (APS) ASICs
Mean time between failure (MTBF):
 CSC = 240,078 hr
 SFC = 276,062 hr
Management
interfaces
Cisco XR 12000 and Cisco 12000 Series Performance Route Processor (PRP) supports two serial
ports (console and auxiliary) and one 10/100 Ethernet port
Indicators and
Interfaces
Visual alarms for critical, major, and minor states on CSCs, SFCs, and on or error condition for
system alarm boards
