Cisco 12000 Series Hardware Installation Guide

Cisco 12000 Series Router SIP and SPA Hardware Installation Guide
Release 12.0(33)S, OL-8831-01, Rev. G9
Chapter 2 Overview: Cisco 12000 Series Router Shared Port Adapters
1-Port 10-Gigabit Ethernet SPA Overview
•
•
•
The XFP temperature range is 0°C to 70°C.
129499
Wavelength (TX) XFP-10GLR: 1260 nm to 1355 nm
XFP-10GER: 1530 nm to1565 nm
Cabling distance
(maximum)
XFP-10GLR: 6.2 miles (10 km)
XFP-10GER: 24.8 miles (40 km)
Operating temperature range XFP-10GLR: -5 to 70 degrees C
XFP-10GER: -5 to 70 degrees C
Storage temperature range XFP-10GLR: -40 to 85 degrees C
XFP-10GER: -40 to 85 degrees C
Tx Power XFP-10GLR: -8.2 to 0.5 dBm
XFP-10GER: -4.7 to 4 dBm
Receiver Sensitivity
(maximum) in OMA
6
XFP-10GLR: -12.6 dBm
XFP-10GER: -14.1 dBm
RX Overload XFP-10GLR: 0.5 dBm
XFP-10GER: -1.0 dBm
Maximum Receiver Power Damage XFP-10GLR: +5 dBm
XFP-10GER: +5 dBm
