Installing the High-Density Electrical Interface Assemblies on the Cisco ONS 15310-MA
78-17418-01
High-Density EIA Description
Figure 1 shows the J connectors on the A- and B-side high-density EIAs installed on the ONS
15310-MA.
Figure 1 High-Density EIA Connectors
Figure 2 shows the A- and B-side high-density EIAs installed on the ONS 15310-MA.
151584
DS1
OUT
J8
DS1
IN
J9
DS1
OUT
J10
DS1
IN
J11
DS1
OUT
J12
DS1
IN
J13
J20-HD DS3
132
PWR AJ6-ALM INPUT
J15-IN J16-OUT J17-IN
J14-OUT J18-OUT J19-IN
PID VID S/N BAR CODE CLEI CODE
P/N
COO
-48VDC RTN
DS1
OUT
J21
DS1
IN
J22
DS1
OUT
J23
DS1
IN
J24
DS1
OUT
J25
DS1
IN
J26
J33-HD DS3
312
PWR B J1-LAN
J31-OUTJ30-INJ29-OUT
J32-INJ28-INJ27-OUT
PID VIDS/NCLEI CODEBAR CODE
P/N
COO
J2-CRFT J3-UDC J4-BITS1RTN -48VDC
J5-BITS2 J7-ALM OUT
