eth1 management interface (labeled 2)
Gigabit Ethernet 100/1000/10000 Mbps interface,
RJ-45, LAN2
4eth0 management interface (labeled 1)
Supports 100/1000/10000 Mbps depending on
link partner capability.
3
CIMC interface (labeled M)
Supported only for Lights-Out Management
access.
6VGA video port (DB-15 connector)5
Unit identification button8Serial console port (RJ-45 connector)
Disabled by default.
7
770-W AC power supply (PSU 2)10770-W AC power supply (PSU 1)9
eth2 management interface
10-Gigabit Ethernet SFP+ support
SFP-10G-SR and SFP-10G-LR are qualified for
use on the management center.
12Threaded holes for dual-hole grounding lug11
Riser handle
Not supported
14eth3 management interface
10-Gigabit Ethernet SFP+ support
SFP-10G-SR and SFP-10G-LR are qualified for
use on the management center.
13
Front Panel LEDs and their States
The following figure illustrates the front panel of the Firepower Management Center 1600, 2600, and 4600,
identifies the LED lights, and provides the information you need to determine appliance status based on the
LEDs. The Firepower Management Center 2600 has four SAS drives, and the Firepower Management Center
4600 has six SAS drives, each with the same drive fault and drive activity LEDs as shown in the diagram.
For information on all the front-panel features, see the Cisco Firepower Management Center 1600, 2600, and
4600 Hardware Installation Guide.
Cisco Firepower Management Center 1600, 2600, and 4600 Getting Started Guide
2
Firepower Management Center 1600, 2600, and 4600 Getting Started Guide
Front Panel LEDs and their States
