Page 13 of 19
– a. Each 2-port analog VIC requires 1 DSP (PVDM-256K-4)
– b. Each VIC-2BRI-NT/TE requires 2 DSPs (PVDM-256K-8)
– c. For VWICs, refer to Table 9. For example, 12 G.711 digital T1/E1 voice calls require two DSPs; 12 G.729
calls require four DSPs
– d. Total DSP requirement is the sum ofa, b and c. The DSP resources can not be shared between analog VICs,
BRI VIC and VWICs.
2. For the Early Deployment (ED) releases: Cisco IOS 12.2(8)YN or later (Note: not including 12.2(11)YT) or T
train releases 12.3(1)T or later, please always refer to the DSP Calculator in the following link:
http://www.cisco.com/cgi-bin/Support/DSP/cisco_prodsel.pl
The DSP calculator optimizes the DSP resources for your configuration and suggests CLI configurations.
Table 7 DSP Firmware for each type of VICs
VIC Type Firmware Support
2-port Analog VICs HC (default), MC ( starting from 12.2(8)YN)
4-port Analog VIC HC, MC (default, starting from 12.2(8)YN)
VIC-2BRI-NT/TE HC (default for ED releases prior to 12.2(8)YN or T train releases prior to 12.3(1)T);
MC; Flexi-6 (default for ED releases 12.2(8)YN or later or T train releases 12.3(1)T or
later);
T1/E1 VWICs Flexi-6 (default)
Table 8 Cisco IOS support for DSP firmware
Firmware Support IOS Release Support
HC In all orderable IOS Releases
MC ED Releases: Cisco IOS 12.2(8)YN or later
1
T Train Releases: Cisco IOS 12.3(1)T or later
1. It doesn’t include Cisco 12.2(11)YT. 12.2(11)YT doesn’t support MC.
Flexi-6 For T1/E1 VWICs:
• ED Releases: Cisco IOS 12.2(4)YB or later
2
• T Train Releases: 6th releases of 12.2T or later
For VIC-2BRI-NT/TE:
• ED Releases: Cisco IOS 12.2(8)YN or later
3
• T Train Releases: Cisco IOS 12.3(1)T or later
2. It doesn’t include Cisco 12.2(11)YT. 12.2(11)YT doesn’t support Flexi-6.
3. It doesn’t include Cisco 12.2(11)YT. 12.2(11)YT doesn’t support Flexi-6.
Table 9 The number of channels supported by one DSP (PVDM-256K-4) per codec type
Firmware
Codec HC (for analog & BRI VICs) MC ( for analog & BRI VICs) Flexi 6 (for VWICs & BRI VIC
1
)
