Installing and Upgrading Internal Modules and FRUs in Cisco 1900 Series ISRs
Modules Internal to the Cisco 1941 Router
17
Installing and Upgrading Internal Modules and FRUs in Cisco 1900 Series ISRs
Figure 14 Removing the Power Supply Cable
Step 4 Locate the power supply. See Figure 3.
Figure 15 Removing the Power Supply
Step 5
Remove the one screw from the power supply as shown in Figure 15.
Step 6 Slide and lift the power supply from the chassis.
249713
199584
DO NOT REMOVE DURING
NETWORK OPERATION
DO NOT REMOVE DURING
NETWORK OPERATION
1
1 Power supply
