Cisco 1721, 1760, 2621XM, 2651XM, 2691, 3725, and 3745 Modular Access Routers and 7206-VXR NPE-400 Router FIPS 140-2 Non-Proprietary
OL-6083-01
The Cisco 1721, 1760, 2621XM, 2651XM, 2691, 3725, 3745, and 7206 VXR NPE-400 Routers
Table 11 Cisco 3725 Rear Panel LEDs and Descriptions
LED Indication Description
CF Solid or blinking green Do not eject Compact Flash (CF); device is busy
Off CF can be ejected; device is idle
FastEthernet 0/0 ACT
and
FastEthernet 0/1 ACT
Solid or blinking green Interface receiving packets
Off Interface not receiving packets
FastEthernet 0/0 LINK
and
FastEthernet 0/1 LINK
Solid green An Ethernet link has been established
Off No Ethernet link established
FastEthernet 0/0 100Mbps
and
FastEthernet 0/1 100Mbps
Solid green The speed of the interface is 10 Mbps or no link is established
Off The speed of the interface is 100 Mbps
Table 12 Cisco 3745 Rear Panel LEDs and Descriptions
LED Indication Description
POWER Solid green Operating voltages on mainboard are within acceptable ranges
Off Error condition is detected in the operating ranges
SYS Solid green Router operating normally
Blinking green Router running ROM monitor; no errors detected
Amber Router receiving power but malfunctioning
Off Router not receiving power
CF Solid or blinking green Do not eject Compact Flash (CF); device is busy
Off CF can be ejected; device is idle
FastEthernet 0/0 ACT
and
FastEthernet 0/1 ACT
Solid or blinking green Interface receiving packets
Off Interface not receiving packets
FastEthernet 0/0 LINK
and
FastEthernet 0/1 LINK
Solid green An Ethernet link has been established
Off No Ethernet link established
FastEthernet 0/0 100Mbps
and
FastEthernet 0/1 100Mbps
Solid green The speed of the interface is 10 Mbps or no link is established
Off The speed of the interface is 100 Mbps
ETM Solid green Enhanced timing module (ETM) present and enabled
Amber ETM present with failure
Off ETM not present
NPA Not used Reserved for future development
AIM0
and
AIM1
Solid green Advanced Integration Module (AIM) present and enabled
Amber AIM present with failure
Off AIM not present
