23
Cisco 1721, 1760, 2621XM, 2651XM, 2691, 3725, and 3745 Modular Access Routers and 7206-VXR NPE-400 Router FIPS 140-2 Non-Proprietary
OL-6083-01
The Cisco 1721, 1760, 2621XM, 2651XM, 2691, 3725, 3745, and 7206 VXR NPE-400 Routers
All of these physical interfaces are separated into the logical interfaces from FIPS 140-2 as described in
Table 15:
ACT Solid or blinking green System is receiving interrupts, or is actively transferring
packets
Off No interrupts or packet transfers are occurring
SYS PS1
and
SYS PS2
Solid green Power supply installed and operating normally
Amber Power supply installed and powered off, or fault condition
occurred
Off Power supply not present, or failed
-48V PS1
and
-48V PS2
Solid green -48V power module installed and operating normally
Amber -48V power module installed and powered off, or fault
condition occurred
Off -48V power module not present, or failed
Table 14 Cisco 3745 Front Panel LEDs and Descriptions (Continued)
LED Indication Description
Table 15 Cisco 3725 and Cisco 3745 FIPS 140-2 Logical Interfaces
Router Physical Interface FIPS 140-2 Logical Interface
10/100BASE-TX LAN Port
WIC Interface
Network Module Interface
Console Port
Auxiliary Port
Compact Flash slot
Data Input Interface
10/100BASE-TX LAN Port
WIC Interface
Network Module Interface
Console Port
Auxiliary Port
Compact Flash slot
Data Output Interface
10/100BASE-TX LAN Port
WIC Interface
Network Module Interface
Power Switch
Console Port
Auxiliary Port
Control Input Interface
