Cisco 2811 and Cisco 2821 Integrated Services Router FIPS 140-2 Non Proprietary Security Policy
OL-8663-01
Cisco 2811 and Cisco 2821 Routers
shows the rear panel. The front panel contains 4 LEDs that output status data about the system power,
auxiliary power, system activity, and compact flash busy status. The back panel consists of 12 LEDs:
two Ethernet activity LEDs, two duplex LEDs, two speed LEDs, two link LEDs, two PVDM LEDs, and
two AIM LEDs.
The front panel contains the following:
• (1) Power inlet
• (2) Power switch
• (3) Optional RPS input
• (4) Console and auxiliary ports
• (5) USB ports
• (6) CF drive
• (7) LEDs described in table 1.
The back panel contains the following:
• (1) Ground connector
• (2) and (3) Ethernet ports and LEDs
• (4)-(7) HWIC slots
• (8) ENM slot.
Table 1 and Table 2 provide more detailed information conveyed by the LEDs on the front and rear panel
of the router:
1. However, an AIM module may not be installed in accordance with this security policy. There is a separate
security policy covering the Cisco 2811 and Cisco 2821 routers with AIM module installed.
Table 1 Cisco 2811 Front Panel Indicators
Name State Description
System Power Off
Blinking Green
Solid Green
Solid Orange
Power off
ROMMON mode
Operating normally
System Error Detected
Auxiliary Power Off
Solid Green
Solid Orange
-48V PS and RPS not present
-48V PS or RPS present and functional
-48V PS or RPS present and failure detected
Activity Off
Blinking Green
Solid Green
No interrupts or packet transfer occurring
System is servicing interrupts
System is actively transferring packets
Compact Flash Off
Solid Green
No ongoing accesses, eject permitted
Device is busy, do not eject

Cisco 2811 Specifications

General

Full duplex	Yes
Networking standards	-
Ethernet LAN data rates	10, 100 Mbit/s
Supports ISDN connection	No
Safety	UL 60950, CAN/CSA C22.2 No. 60950, IEC 60950, EN 60950-1, AS/NZS 60950
Flash memory	128 MB
Internal memory	256 MB
I/O ports	2 x USB\\r 2 x 10/100 Base-T
Ethernet LAN (RJ-45) ports	2
Storage temperature (T-T)	-40 - 70 °C
Firewall security	Cisco IOS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES
Product color	Blue, Stainless steel
Rack capacity	1U

Weight and Dimensions

Depth	416.6 mm
Width	438.2 mm
Height	44.5 mm
Weight	6400 g
