5
Cisco 2811 and Cisco 2821 Integrated Services Router FIPS 140-2 Non Proprietary Security Policy
OL-8663-01
Cisco 2811 and Cisco 2821 Routers
Table 3 describes the meaning of Ethernet LEDs on the rear panel:
The physical interfaces are separated into the logical interfaces from FIPS 140-2 as described in the
Table 4:
Table 2 Cisco 2811 Rear Panel Indicators
Name State Description
PVDM1 Off
Solid Green
Solid Orange
PVDM1 not installed
PVDM1 installed and initialized
PVDM1 installed and initialized error
PVDM0 Off
Solid Green
Solid Orange
PVDM0 not installed
PVDM0 installed and initialized
PVDM0 installed and initialized error
AIM1 Off
Solid Green
Solid Orange
AIM1 not installed
AIM1 installed and initialized
AIM1 installed and initialized error
AIM0 Off
Solid Green
Solid Orange
AIM0 not installed
AIM0 installed and initialized
AIM0 installed and initialized error
Table 3 Cisco 2811 Ethernet Indicators
Name State Description
Activity Off
Solid/Blinking
Green
Not receiving packets
Receiving packets
Duplex Off
Solid Green
Half-Duplex
Full-Duplex
Speed One Blink Green
Two Blink Green
10 Mbps
100 Mbps
Link Off
Solid Green
No link established
Ethernet link is established

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco 2811 and is the answer not in the manual?

Cisco 2811 Specifications

General IconGeneral
Full duplexYes
Networking standards-
Ethernet LAN data rates10, 100 Mbit/s
Supports ISDN connectionNo
SafetyUL 60950, CAN/CSA C22.2 No. 60950, IEC 60950, EN 60950-1, AS/NZS 60950
Flash memory128 MB
Internal memory256 MB
I/O ports2 x USB\\r 2 x 10/100 Base-T
Ethernet LAN (RJ-45) ports2
Storage temperature (T-T)-40 - 70 °C
Firewall securityCisco IOS
Security algorithms128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES
Product colorBlue, Stainless steel
Rack capacity1U
Weight and Dimensions IconWeight and Dimensions
Depth416.6 mm
Width438.2 mm
Height44.5 mm
Weight6400 g
