Cisco 2811 User Manual

6
Cisco 2811 and Cisco 2821 Integrated Services Router FIPS 140-2 Non Proprietary Security Policy
OL-8663-01
Cisco 2811 and Cisco 2821 Routers
There are two USB ports but they are not supported currently. The ports will be supported in the future
for smartcard or token reader.
The CF card that stored the IOS image is considered an internal memory module, because the IOS image
stored in the card may not be modified or upgraded. The card itself must never be removed from the
drive. Tamper evident seal will be placed over the card in the drive.
Table 4 Cisco 2811 FIPS 140-2 Logical Interfaces
Router Physical Interface FIPS 140-2 Logical Interface
10/100 Ethernet LAN Ports
HWIC Ports
Console Port
Auxiliary Port
ENM Slot
Data Input Interface
10/100 Ethernet LAN Ports
HWIC Ports
Console Port
Auxiliary Port
ENM Slot
Data Output Interface
10/100 Ethernet LAN Ports
HWIC Ports
Power Switch
Console Port
Auxiliary Port
ENM Slot
Control Input Interface
10/100 Ethernet LAN Port LEDs
AIM LEDs
PVDM LEDs
Power LED
Activity LEDs
Auxiliary LED
Compact Flash LED
Console Port
Auxiliary Port
Status Output Interface
Main Power Plug
Redundant Power Supply Plug
Power Interface

Cisco 2811 Specifications

General

Full duplex	Yes
Networking standards	-
Ethernet LAN data rates	10, 100 Mbit/s
Supports ISDN connection	No
Safety	UL 60950, CAN/CSA C22.2 No. 60950, IEC 60950, EN 60950-1, AS/NZS 60950
Flash memory	128 MB
Internal memory	256 MB
I/O ports	2 x USB\\r 2 x 10/100 Base-T
Ethernet LAN (RJ-45) ports	2
Storage temperature (T-T)	-40 - 70 °C
Firewall security	Cisco IOS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES
Product color	Blue, Stainless steel
Rack capacity	1U

Weight and Dimensions

Depth	416.6 mm
Width	438.2 mm
Height	44.5 mm
Weight	6400 g
