Cisco 2811 and Cisco 2821 Integrated Services Router FIPS 140-2 Non Proprietary Security Policy
OL-8663-01
Cisco 2811 and Cisco 2821 Routers
The Cisco 2821 Cryptographic Module Physical Characteristics
Figure 4 The Cisco 2821 router case
The Cisco 2821 router a multiple-chip standalone cryptographic module. The router has a processing
speed of 350MHz. Depending on configuration, either the internal NetGX chip or the IOS software is
used for cryptographic operations.
The cryptographic boundary of the module is the device's case. All of the functionality discussed in this
document is provided by components within this cryptographic boundary.
The interfaces for the router are located on the front and rear panel as shown in Figure 5and Figure 6,
respectively.
Figure 5 Cisco 2821 Front Panel Physical Interfaces
95903
Do Not Remove During Network O
peration
COMPACT FLASH
CONSOLE
AUX
SYS
PWR
AUX/
PW
R
SYS
ACT
CF
0
1
O
P
T
IO
N
A
L
R
P
S
IN
P
U
T
1
2
V
1
1
A
-48
V
4
A
100-2
40 V~
4A
50/60 Hz
95553
Do Not Remove During Network Operation
COMPACT FLASH
0
1
OPTIONAL RPS INPUT
SYS
PWR
AUX/
PWR
SYS
ACT CF
12V 18A
100-240 V~ 3A
50/60 Hz
1457 6 3
CONSOLE
AUX
2

Cisco 2811 Specifications

General

Full duplex	Yes
Networking standards	-
Ethernet LAN data rates	10, 100 Mbit/s
Supports ISDN connection	No
Safety	UL 60950, CAN/CSA C22.2 No. 60950, IEC 60950, EN 60950-1, AS/NZS 60950
Flash memory	128 MB
Internal memory	256 MB
I/O ports	2 x USB\\r 2 x 10/100 Base-T
Ethernet LAN (RJ-45) ports	2
Storage temperature (T-T)	-40 - 70 °C
Firewall security	Cisco IOS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES
Product color	Blue, Stainless steel
Rack capacity	1U

Weight and Dimensions

Depth	416.6 mm
Width	438.2 mm
Height	44.5 mm
Weight	6400 g
