Page #3 background imageLoading...
Page #3 background image
Cisco 4000 Series Rack-Mount and Wall-Mount Installation 3
Required Tools and Parts
Determine if the person needs rescue breathing or external cardiac compressions; then take
appropriate action.
Required Tools and Parts
The following tools and parts are required for rack-mount and wall-mount procedures:
Screwdriver, number 1 or number 2 Phillips
Screwdriver, number 2 flat-blade
For wall-mounting, the following additional equipment is required:
Plywood board (19 x 19 x 1/2 inch minimum size)
Wood fasteners for attaching the board to the wall
Table 1 lists the parts contained in the standard rack-mount kit.
Table 1 Standard Rack-Mount Kit Components
Table 2 lists the parts contained in the telco rack-mount and wall-mount kit.
Table 2 Telco Rack-Mount and Wall-Mount Kit Components
Overview of Rack-Mount and Wall-Mount Procedures
The Cisco 4000 series routers can be mounted in a standard 19-inch rack, a telco 19-inch rack, or on
a wall. The procedures for the different mounting options involve removing the front panel and
component tray from the chassis shell and then installing the empty shell in position before
reinserting the component tray.
Quantity Item
2 Rack-mount brackets
2 Short bracket extenders
2 Long bracket extenders
6 M3 machine screws
8 10-32 machine screws
8 8-32 flat-head machine screws
1 Installation diagram
Quantity Item
2 Telco rack-mount or wall-mount brackets
2 M3 machine screws
4 10-32 machine screws
8 8-32 flat-head machine screws
4 Hex-head wood screws (mounts chassis to plywood board)
1 Installation diagram
