Cisco Content Router 4430 Hardware Installation Guide
78-12541-01
Chapter 1 Introducing the Content Router 4430
System Hardware Features
Warning
To avoid electric shock, do not connect safety extra-low voltage
(SELV) circuits to telephone-network voltage (TNV) circuits. LAN
ports contain SELV circuits, and WAN ports contain TNV circuits.
Some LAN and WAN ports both use RJ-45 connectors. Use caution
when connecting cables.
Table 1-3 describes the LEDs on the front panel.
Slot 0 Bay for hard drive 0.
Slot 1 Bay not used.
Back Panel
Power receptacle The power cord connects to this plug.
Power switch This switch toggles between on and off, even though
the switch always returns to its initial position after
you press it.
A power light on the front panel, when lit, indicates
that the power is on.
Table 1-2 Ports and Receptacles (continued)
Item Description
Ta b l e 1- 3 L E D s
Indicator Color State Description
Power Green On Power is flowing to the Content Router.
System Green On The network connection is active
(packets are being sent or received).
LINK Green On The Content Router is connected to the
network.
100 Mbps Green On The connection is a 100BASE-TX
(Fast Ethernet) connection.
Slot 0 Green On Slot 0 is active.
Slot 1 Green On Slot 1 is active.
