1 Hardware Description 78-5296-02 10/02/98
Cisco 6200 User Guide1-26
1.5.3 SLC 8CAP Specifications
Table 1-10 lists the physical and electrical specifications of the CAP SLC (SLC 8CAP).
Table 1-10 SLC 8CAP Specifications
Specification Description
Subscriber ports 8 per card
Transmission speeds Downstream: up to 7 Mbps
Upstream: up to 1 Mbps
Loop hardware media Unshielded twisted pair copper wire
Loop modulation method ADSL with CAP line code
Layer 2 format ATM (service and subscriber side, end-to-end)
ATM virtual circuits supported Up to 31 per subscriber, numbered 33 through 63 (VPI 0)
Data channel frequencies • Upstream: 30 to 200 kHz
• Downstream: 240 kHz to 1.5 MHz
Internal hardware • Motorola MC68360
• 1 Mbyte Flash memory
• 512 kbyte Flash boot memory
• Globespan CAP chip set
• Cisco ATM framer
Dimensions
(width x height x depth)
1.17 x 15.75 x 9.75 in
(3.0 x 40.0 x 24.8 cm)
Weight 3 lb (1.36 kg)
Power consumption 72W
