Figure 1-13 SLC 8DMT Faceplate
Reset Switch
The reset switch is recessed behind the faceplate to avoid accidental activation. It is not for customer
use.
LED Indicators
Table 1-11 describes the LEDs on the faceplate of the SLC.
13067
SLC
8DMT
PORTS
1
2
3
4
5
6
7
POWER
READY
PRIME
SEC
0
Card status LEDs
Port status LEDs
Reset switch
