30
Step 3 During the boot process, observe the system LEDs. The STATUS LED comes on immediately as amber, then turns to
green when the Cisco IOS is booted. Port adapter LEDs go on and off irregularly.
Step 4 Observe the initialization process. The port adapter ENABLED LEDs go on when initialization is completed and the
console screen displays a script and system banner.
Proceed to the “Configure the Router” section on page 31 to configure the router.
6
PWR OK Power Solid green The power-on is successful and the system
is attempting to boot software, or has
booted software.
Off Off, the router is in standby mode.
7
STATUS System status Solid green Cisco IOS has successfully booted.
Blinking amber ROMmon is loading.
Blinking green Cisco IOS is loading.
8
CF ACTV CompactFlash Disk Flashing green Activity
Off No activity
No. LED Label LED
In the Power Up State
Color-Activityr Behavior Description
